1. Product Overview
The ELEM-NB5060J6J8293910-F3C is a high-performance, surface-mount white LED designed for applications requiring high luminous output and reliability. This device utilizes InGaN chip technology to produce white light with a typical correlated color temperature (CCT) of 5500K. Its compact 5.0mm x 6.0mm package makes it suitable for space-constrained designs while delivering a typical luminous flux of 260 lumens at a forward current of 1000mA.
The LED is engineered with robust features including ESD protection rated up to 8KV, making it suitable for environments where electrostatic discharge is a concern. It is fully compliant with RoHS (Restriction of Hazardous Substances) directives, EU REACH regulations, and is manufactured as halogen-free, ensuring environmental safety and meeting global regulatory standards for electronic components.
1.1 Core Advantages and Target Market
The primary advantages of this LED are its combination of small form factor and high optical efficiency. The typical luminous efficacy is significant for its package size. The device is grouped by key parameters such as total luminous flux and color coordinates, providing consistency for batch production in lighting applications.
The target market is broad, encompassing consumer electronics and professional lighting. Key application areas identified include mobile phone camera flash modules, where high-intensity pulsed light is required; torch lights for digital video equipment; various indoor and outdoor general lighting applications; backlighting for displays; and decorative or automotive lighting. Its performance characteristics make it a versatile choice for designers seeking a reliable, bright white light source.
2. Technical Parameter Analysis
2.1 Absolute Maximum Ratings
The device has strict operational limits to ensure longevity and prevent damage. The absolute maximum ratings are specified at a solder pad temperature (Tsolder pad) of 25\u00b0C.
- DC Forward Current (IF): 350 mA (continuous operation).
- Peak Pulse Current (IPulse): 1000 mA. This is specified for a pulse duration of 400ms ON and 3600ms OFF, representing a maximum duty cycle of 10%. Exceeding this can cause permanent damage.
- ESD Resistance (Human Body Model): 8000 V.
- Reverse Voltage (VR): Note: The LED is not designed for reverse bias operation. Applying reverse voltage can damage the device.
- Junction Temperature (TJ): 115 \u00b0C (maximum).
- Operating & Storage Temperature: -40 \u00b0C to +85 \u00b0C.
- Power Dissipation (Pulse Mode): 3.95 W.
- Soldering Temperature: 245 \u00b0C (peak during reflow).
- Viewing Angle (2\u03b81/2): 120 degrees (\u00b1 5\u00b0 tolerance). This is the full angle at which luminous intensity is half the peak value.
Critical Design Notes: Operating the LED at maximum ratings for extended periods (exceeding 1 hour) is not recommended as it can lead to reliability issues and potential permanent damage. All reliability testing was performed under good thermal management using a 1.0 cm x 1.0 cm Metal Core Printed Circuit Board (MCPCB). Designers must implement proper heat sinking to maintain the solder pad temperature within safe limits.
2.2 Electro-Optical Characteristics
The key performance parameters are measured under pulsed conditions (50ms pulse width) at Tsolder pad = 25\u00b0C. This minimizes self-heating effects during measurement.
- Luminous Flux (\u03a6v): Minimum 240 lm, Typical 260 lm. Measurement tolerance is \u00b110%.
- Forward Voltage (VF): Minimum 2.95V, Typical 3.3V, Maximum 3.95V at IF=1000mA. Measurement tolerance is \u00b10.1V. The forward voltage is a critical parameter for driver design and power consumption calculation.
- Correlated Color Temperature (CCT): 5000K to 6000K, with a typical value of 5500K. This places the white light output in the \"cool white\" or \"daylight white\" range.
3. Binning System Explanation
The product uses a multi-parameter binning system to ensure consistency. The part number ELEM-NB5060J6J8293910-F3C encodes specific bin codes.
3.1 Forward Voltage Binning
LEDs are sorted into bins based on their forward voltage at 1000mA.
- Bin Code \"2935\": VF range from 2.95V to 3.55V.
- Bin Code \"3539\": VF range from 3.55V to 3.95V.
The part number indicates a bin code of \"2939\\
